Descripción
| Hardware Specifications | |
|---|---|
| Hardware Version | 9 |
| 10/100/1000BASE-T MDI/MDIX Ports |
16 |
| Throughput (packet per second) | 23,8Mpps |
| Switch fabric | 32 Gbps |
| Weight | 1,8 kg |
| Power Consumption/Dissipation | 9,4 Watts/32 BTU |
| Power Requirements | 100~240 V CA, 0,16 A, 50-60 Hz |
| Dimensions (W x D x H) |
440 x 208 x 44 mm, 1U of height |
| Switch Processing Scheme | Store-and-Forward |
| Address Table | 8K entries |
| Jumbo Packet Size | 9K |
| Flow Control | Back pressure for half duplex IEEE 802.3x Pause Frame for full duplex |
| Dip switch |
Operation mode selection: Standard, Flow control off, VLAN, Extend　 |
| Regulatory Compliance | FCC Part 15 Class A, CE |
|
Standards Compliance |
IEEE 802.3 (Ethernet) IEEE 802.3u (Fast Ethernet) IEEE 802.3ab (Gigabit Ethernet) IEEE 802.3x (Full-Duplex Flow Control) IEEE 802.3az Energy Efficient Ethernet (EEE) |
| Operating | Operating Temperature: 0~50 degrees C Relative Humidity: 5% to 95% (non-condensing) |
| Storage temperature |
Temperature: -10~70 degrees C Relative Humidity: 5% to 95% (non-condensing) |
|
Package content |
– 1 Switch GSW-1601 – 1 power supplu cable – 2 mounting for rack – 1 user manual |
|
Warranty |
3 Years |
